| Specification |
Details |
| Authentication Method |
Fingerprint / Smart Card / RFID Card |
| CPU |
1.4GHz Quad-Core Cortex A9 |
| RAM |
2GB RAM |
| Flash Memory |
8GB eMMC Flash |
| User Capacity |
Up to 500,000 Users |
| Fingerprint Templates |
200,000 Templates (1:N, 1:1) |
| Event Logs |
10,000,000 Logs |
| Image Logs |
50,000 Images |
| Matching Speed |
200,000 Templates in 1 Second |
| Fingerprint Sensor |
Optical Sensor |
| Fingerprint Resolution |
500 dpi |
| Platen Area |
16.4 × 19.4 mm |
| LCD Display |
5″ Color TFT Touch LCD |
| Screen Resolution |
480 × 854 |
| Camera |
Built-in Camera |
| Communication |
TCP/IP, USB, RS232, RS485, Wiegand In/Out |
| Wireless Connectivity |
Optional Wi-Fi |
| Supported Cards |
125KHz EM, HID Prox, HID iClass, 13.56MHz Smart Card |
| Keypad |
Touch Screen |
| Operating Temperature |
-20°C ~ 60°C |
| Humidity |
Below 90% RH |
| FRR / FAR |
0.1% / 0.0001% |
| Power Supply |
DC 12V ~ 24V |
| Dimensions |
80 × 195.6 × 23.5 mm |
| Applications |
Access Control & Time Attendance |
